Edose Dosing Pump

Get a Price/Quote

MOQ : 1 Unit

Edose Dosing Pump Specification

Theory
Electromagnetic Diaphragm Pump

Flow Rate
0-6 LPH (liters per hour)

Material
Body: Polypropylene (PP), Diaphragm: Teflon/PTFE, Seals: Viton or Teflon

Structure
Compact Modular Design

Suction Type
Positive Suction

Volute Type
Single-Stage

Nozzle Location
End Suction

Shaft Orientation
Horizontal

Power Source
Electric

Pressure
Max 5 kg/cm2 (customizable up to 12 kg/cm2)

Temperature
Up to 60C

Inlet, Outlet Diameter
Standard: 8 mm OD, Custom Available

Speed
Adjustable; Manual Stroke Regulation (10 to 100% control)

Application
Water Treatment, Chemical Dosing, Effluent Treatment, Boiler Feed

Maximum Viscosity Handling
Up to 1000 cP

Frequency
50/60 Hz

Mounting Type
Wall and Foot Mounting Available

Voltage
230 V AC (Also available in 110 V AC)

Weight
Approx. 2.8 kg

Power Consumption
10-15 Watts

Dimension
190 x 125 x 140 mm

Control Method
Manual and Optional Digital (Pulse) Control

Safety Feature
Non-Return Valve built-in

Discharge Tubing Material
PVC/PP/PU

Protection Class
IP65 (Weatherproof housing)

Accessories Included
Foot Valve, Injection Valve, Suction & Delivery Tubes

Suction Lift
Up to 1.5 meters

Edose Dosing Pump Trade Information

Minimum Order Quantity
1 Unit

Supply Ability
100 Units Per Month

Delivery Time
2-10 Days

Main Domestic Market
All India

About Edose Dosing Pump

Reserve your Edose Dosing Pump now to seize this Hot Deal at a Reduced Price-crafted for those seeking a valorous blend of sublime performance and lofty reliability. This dosing pump offers manual and optional digital (pulse) control, is compatible with wall or foot mounting, and delivers energy-saving operation at just 10-15 watts. With IP65 weatherproofing and a robust polypropylene build, it handles up to 1000 cP and 12 kg/cm2 pressure, making it ideal for water treatment, boiler feed, and chemical dosing applications in demanding industrial environments.

Edose Dosing Pump: Applications & Features

Designed for versatility, the Edose Dosing Pump excels in water treatment, chemical dosing, effluent management, and boiler feed systems. With a compact modular structure and robust IP65-rated weatherproof housing, it features a sublime manual or optional digital (pulse) control method. The pump is adjustable for varied flow rates and can handle up to 1000 cP viscosity, ensuring valorous efficiency in critical industrial settings. Accessories like foot valve, suction, and delivery tubes are included for seamless installation and operation.

Swift Supply, Sample Policies & Delivery Support

Our packing & dispatch process ensures your Edose Dosing Pump reaches you safely, supported by reliable transport services for both domestic and international clients. We offer quick dispatch from India's major FOB ports and can provide samples as per policy for qualified inquiries. Our commitment to timely delivery and careful packaging aligns with our lofty goal of client satisfaction, making us a preferred exporter, manufacturer, supplier, and trader for industrial dosing solutions.

FAQ's of Edose Dosing Pump:

Q: How can I control the Edose Dosing Pump during operation?

A: The Edose Dosing Pump offers both manual and optional digital (pulse) control methods, allowing flexible management of dosing speed and accuracy according to process needs.

Q: What are the main application areas for the Edose Dosing Pump?

A: It is engineered for water treatment, chemical dosing, effluent treatment, and boiler feed, making it suitable for diverse industrial processes that require precise dosing and reliable operation.

Q: Where can the Edose Dosing Pump be mounted?

A: This pump is designed for easy installation, with both wall and foot mounting options available to suit different spatial and operational requirements.

Q: What materials are used in the pump's construction for durability?

A: The Edose Dosing Pump features a polypropylene (PP) body, a Teflon/PTFE diaphragm, and Viton or Teflon seals, ensuring chemical resistance and long-term valorous performance.

Q: What accessories and safety features come with the Edose Dosing Pump?

A: Each unit includes foot valve, injection valve, suction and delivery tubes, and is equipped with a non-return valve to prevent backflow and guarantee safe operation.

Q: How does the supply and delivery process work for international orders?

A: We provide comprehensive packing & dispatch solutions, utilize dependable transport services, and offer swift shipment from major Indian FOB ports, ensuring global clients receive prompt and secure deliveries.
